Una guida didattica di installazione completa di Alfresco Community dal pacchetto ZIP.

Requisiti

• OS: Ubuntu Server 24.04 LTS
• Java: OpenJDK 17
• Application server: Apache Tomcat 10.1
• Database: MariaDB 11.3
• Database : MariaDB JDBC connector 2.7.12
• Message Broker: ActiveMQ 6.1.2
• Document Processor: LibreOffice 24.2
• Image Processor: ImageMagick 6.9
• Reverse Proxy; Nginx 1.24

Procedura

Iniziamo installando i programmi di pre-requisito nel server (JRE, database, and message broker) prima di procedere.

1. Installiamo i software di terze parti (LibreOffice, ImageMagick e Alfresco PDF Renderer);
2. installiamo ActiveMQ;
3. creiamo il DB per Alfresco;
4. installiamo Tomcat;
5. installiamo Alfresco Community 23;
6. installiamo Alfresco Module Package (AMP);
7. Installiamo Alfresco Transformer Service (ATS);
8. primo avvio.

1. Installiamo i software di terze parti

• Dopo aver installato Ubuntu 24, aggiorniamolo

sudo apt update
sudo apt full-upgrade -y

• installiamo i software di terze parti

sudo apt install -y htop neofetch wget apt-transport-https curl openssl
sudo apt install -y openjdk-17-jdk openjdk-17-jdk-headless openjdk-17-jre openjdk-17-jre-headless
sudo apt install -y imagemagick
sudo apt install -y libreoffice
sudo apt install -y libimage-exiftool-perl

• Installiamo MariaDB

sudo curl -o /etc/apt/trusted.gpg.d/mariadb-keyring.pgp 'https://mariadb.org/mariadb_release_signing_key.pgp'

sudo echo "# MariaDB 11.3 repository list - created 2024-06-02 21:39 UTC
# https://mariadb.org/download/
X-Repolib-Name: MariaDB
Types: deb
# deb.mariadb.org is a dynamic mirror if your preferred mirror goes offline. See https://mariadb.org/mirrorbits/ for details.
# URIs: https://deb.mariadb.org/11.3/ubuntu
URIs: https://mirror.mva-n.net/mariadb/repo/11.3/ubuntu
Suites: mantic
Components: main main/debug
Signed-By: /etc/apt/trusted.gpg.d/mariadb-keyring.pgp" > /etc/apt/sources.list.d/mariadb.sources

sudo apt update
sudo apt install -y mariadb-server

• attiviamo e avviamo MariaDB

systemctl start mariadb
systemctl status mariadb

• inizializziamo MariaDB

mariadb-secure-installation

NOTE: RUNNING ALL PARTS OF THIS SCRIPT IS RECOMMENDED FOR ALL MariaDB
SERVERS IN PRODUCTION USE! PLEASE READ EACH STEP CAREFULLY!

In order to log into MariaDB to secure it, we'll need the current
password for the root user. If you've just installed MariaDB, and
haven't set the root password yet, you should just press enter here.

Enter current password for root (enter for none):
OK, successfully used password, moving on...

Setting the root password or using the unix_socket ensures that nobody
can log into the MariaDB root user without the proper authorisation.

You already have your root account protected, so you can safely answer 'n'.

Switch to unix_socket authentication [Y/n] y
Enabled successfully!
Reloading privilege tables..
... Success!


You already have your root account protected, so you can safely answer 'n'.

Change the root password? [Y/n] y
New password: YourSecureMainPassword
Re-enter new password: YourSecureMainPassword
Password updated successfully!
Reloading privilege tables..
... Success!


By default, a MariaDB installation has an anonymous user, allowing anyone
to log into MariaDB without having to have a user account created for
them. This is intended only for testing, and to make the installation
go a bit smoother. You should remove them before moving into a
production environment.

Remove anonymous users? [Y/n] y
... Success!

Normally, root should only be allowed to connect from 'localhost'. This
ensures that someone cannot guess at the root password from the network.

Disallow root login remotely? [Y/n] y
... Success!

By default, MariaDB comes with a database named 'test' that anyone can
access. This is also intended only for testing, and should be removed
before moving into a production environment.

Remove test database and access to it? [Y/n] y
- Dropping test database...
... Success!
- Removing privileges on test database...
... Success!

Reloading the privilege tables will ensure that all changes made so far
will take effect immediately.

Reload privilege tables now? [Y/n] y
... Success!

Cleaning up...

All done! If you've completed all of the above steps, your MariaDB
installation should now be secure.

Thanks for using MariaDB!

2. Installiamo ActiveMQ

( https://www.howtoforge.com/how-to-install-apache-activemq-on-ubuntu-20-04/ )

• Scarichiamo il pacchetto

mkdir SW && cd SW
wget -O apache-activemq-6.1.2-bin.tar.gz "https://www.apache.org/dyn/closer.cgi?filename=/activemq/6.1.2/apache-activemq-6.1.2-bin.tar.gz&action=download"

tar xfz apache-activemq-6.1.2-bin.tar.gz -C /opt/
mv /opt/apache-activemq-6.1.2 /opt/activemq

sudo groupadd -r activemq
sudo useradd -d /opt/activemq -M -r -g activemq -s /usr/sbin/nologin activemq

sudo chown activemq:activemq -R /opt/activemq

sudo nano /usr/lib/systemd/system/activemq.service

[Unit]
Description=Apache ActiveMQ
After=network.target

[Service]
Type=forking
User=activemq
Group=activemq

ExecStart=/opt/activemq/bin/activemq start
ExecStop=/opt/activemq/bin/activemq stop

[Install]
WantedBy=multi-user.target

sudo systemctl daemon-reload
sudo systemctl start activemq

3. Creiamo il DB per Alfresco

• Eseguiamo la query

mariadb -u root -e "CREATE DATABASE alfresco CHARACTER SET utf8 COLLATE utf8_general_ci;"
mariadb -u root -e "CREATE USER alfresco@localhost IDENTIFIED BY 'alfrescoPass';"
mariadb -u root -e "GRANT ALL ON alfresco.* TO alfresco@localhost IDENTIFIED BY 'alfrescoPass';"
mariadb -u root -e "FLUSH PRIVILEGES;"
mariadb -u root -e "SHOW DATABASES;"

• Aggiorniamo la configurazione di MariaDB server

sudo nano /etc/mysql/mariadb.conf.d/50-server.cnf

[ ... ]
#max_connections = 100
max_connections = 275
[ ... ]

• riavviamo MariaDB server

sudo systemctl restart mariadb

4. Installiamo Tomcat

• Scarichiamo Tomcat 10.1.24

cd ~ && cd SW
mkdir /opt/alfresco
wget https://dlcdn.apache.org/tomcat/tomcat-10/v10.1.24/bin/apache-tomcat-10.1.24.tar.gz

tar xfz apache-tomcat-10.1.24.tar.gz -C /opt/alfresco
mv /opt/alfresco/apache-tomcat-10.1.24 /opt/alfresco/tomcat

chmod +x /opt/alfresco/tomcat/bin/*.sh
rm /opt/alfresco/tomcat/bin/*.bat

sudo nano /usr/lib/systemd/system/alfresco.service

[Unit]
Description=Alfresco Platform
After=network.target

[Service]
Type=forking
User=alfresco
Group=alfresco

ExecStart=/opt/alfresco/tomcat/bin/startup.sh
ExecStop=/opt/alfresco/tomcat/bin/shutdown.sh

[Install]
WantedBy=multi-user.target

sudo systemctl daemon-reload

• aggiungere il connector JDBC MariaDB in Tomcat

cd ~ && cd SW
wget https://dlm.mariadb.com/3752064/Connectors/java/connector-java-2.7.12/mariadb-java-client-2.7.12.jar
sudo cp mariadb-java-client-2.7.12.jar /opt/alfresco/tomcat/lib/

• cancelliamo quanto contenuto in webapps

sudo rm -R /opt/alfresco/tomcat/webapps/*

5. Installiamo Alfresco Community 23

• Scarichiamo Alfresco 23 e Alfresco SSL Generator

cd ~ && cd SW
mkdir alfresco

wget https://nexus.alfresco.com/nexus/service/local/repositories/releases/content/org/alfresco/alfresco-content-services-community-distribution/23.2.1/alfresco-content-services-community-distribution-23.2.1.zip -O alfresco/alfresco-content-services-community-distribution-23.2.1.zip
wget -O alfresco-ssl-generator.zip https://github.com/Alfresco/alfresco-ssl-generator/archive/refs/heads/master.zip

unzip alfresco-ssl-generator.zip

cd alfresco
unzip alfresco-content-services-community-distribution-23.2.1.zip

sudo mv ../alfresco-ssl-generator-master/ssl-tool /opt/alfresco/
sudo mv web-server/webapps/* /opt/alfresco/tomcat/webapps/
sudo mv web-server/shared /opt/alfresco/tomcat/
sudo mv web-server/lib/* /opt/alfresco/tomcat/lib/
sudo cp -R web-server/conf/Catalina /opt/alfresco/tomcat/conf/
sudo mkdir -p /opt/alfresco/data /opt/alfresco/logs /opt/alfresco/modules/{platform,share} /opt/alfresco/tomcat/shared/classes/lib
sudo mv keystore /opt/alfresco/data/
sudo mv amps /opt/alfresco/
sudo mv bin /opt/alfresco/
sudo mv licenses /opt/alfresco/

rm -R web-server

• aggiorniamo alfresco.xml e share.xml

sudo nano /opt/alfresco/tomcat/conf/Catalina/localhost/alfresco.xml

[ ... ]
<PostResources base="/opt/alfresco/modules/platform"
[ ... ]

sudo nano /opt/alfresco/tomcat/conf/Catalina/localhost/share.xml

[ ... ]
<PostResources base="/opt/alfresco/modules/share"
[ ... ]

• generiamo i certificati per il TLS reciproco

cd /opt/alfresco/ssl-tool/
bash ./run.sh -keystorepass keystore -truststorepass keystore

• copiamo i certificati

sudo cp -R /opt/alfresco/ssl-tool/keystores/* /opt/alfresco/data/keystore/.
sudo cp -R /opt/alfresco/ssl-tool/certificates /opt/alfresco/data/keystore/.
sudo cp -R /opt/alfresco/ssl-tool/ca /opt/alfresco/data/keystore/.

• editiamo /opt/alfresco/tomcat/conf/catalina.properties e integriamo shared.loader=

sudo nano /opt/alfresco/tomcat/conf/catalina.properties

[ ... ]
shared.loader="${catalina.base}/shared/classes","${catalina.base}/shared/lib/*.jar"
[ ... ]

• creiamo /opt/alfresco/tomcat/bin/catalina.sh

sudo nano /opt/alfresco/tomcat/bin/setenv.sh

#
# Set to certificate

JAVA_OPTS="$JAVA_OPTS -Dencryption.keystore.type=JCEKS -Dencryption.cipherAlgorithm=DESede/CBC/PKCS5Padding -Dencryption.keyAlgorithm=DESede -Dencryption.keystore.location=/opt/alfresco/data/keystore/metadata-keystore/keystore -Dmetadata-keystore.password=mp6yc0UD9e -Dmetadata-keystore.aliases=metadata -Dmetadata-keystore.metadata.password=oKIWzVdEdA -Dmetadata-keystore.metadata.algorithm=DESede"


#
# Setting for Alfresco JVM

JAVA_OPTS="-Xms1G -Xmx5G $JAVA_OPTS "

sudo chmod +x /opt/alfresco/tomcat/bin/setenv.sh

• aggiorniamo server.xml

sudo nano /opt/alfresco/tomcat/conf/server.xml

[ ... ]
<Connector port="8080" protocol="HTTP/1.1"
connectionTimeout="20000"
redirectPort="8443"
maxParameterCount="1000"
URIEncoding="UTF-8"
maxHttpHeaderSize="32768"
/>
[ ... ]

• impostiamo il proprietario

sudo groupadd -r alfresco
sudo useradd -d /opt/alfresco -M -r -g alfresco -s /usr/sbin/nologin alfresco

sudo chown alfresco:alfresco -R /opt/alfresco

6. Installiamo Alfresco Module Package (AMP)

( https://docs.alfresco.com/content-services/community/install/zip/amp/ )

• Lanciamo apply_amps.sh come utente alfresco

sudo su - -s /bin/bash alfresco
cd /opt/alfresco/bin
bash apply_amps.sh
exit

7. Installiamo Alfresco Transformer Service (ATS)

( https://docs.alfresco.com/transform-service/latest/ )

• Scarichiamo Alfresco PDF Render

cd ~ && cd SW
wget https://nexus.alfresco.com/nexus/service/local/repositories/releases/content/org/alfresco/alfresco-pdf-renderer/1.2/alfresco-pdf-renderer-1.2-linux.tgz

• pubblichiamo alfresco-pdf-renderer

sudo tar xfz alfresco-pdf-renderer-1.2-linux.tgz -C /opt/alfresco/bin/
sudo chmod -x /opt/alfresco/bin/alfresco-pdf-renderer

• scarichiamo Alfresco Transform Core

wget https://nexus.alfresco.com/nexus/service/local/repositories/releases/content/org/alfresco/alfresco-transform-core-aio-boot/2.7.0-A1/alfresco-transform-core-aio-boot-2.7.0-A1.jar

• pubblichiamo Alfresco Transform Core

sudo cp alfresco-transform-core-aio-boot-2.7.0-A1.jar /opt/alfresco/bin/

• creiamo lo script per eseguire Alfresco Transform Service

sudo nano /opt/alfresco/bin/alfrescots.sh

#!/bin/bash

#
# Set global variables
#
SERVICE_NAME=LTS_-_Local_Tranfromation_Service
LOCAL_TRANSFORM_SERVICE_HOME=/opt/alfresco
PID_PATH_NAME=$LOCAL_TRANSFORM_SERVICE_HOME/tomcat/temp/LTS.pid

#
# Set Variables of run application
#

# -DPDFRENDERER_EXE
TS_PDFRENDERER=/opt/alfresco/bin/alfresco-pdf-renderer

# -DLIBREOFFICE_HOME
TS_OFFICE=/usr/lib/libreoffice

# -DIMAGEMAGICK_ROOT -DIMAGEMAGICK_DYN
TS_IMAGEMAGICK=/usr/bin

# -DIMAGEMAGICK_EXE
TS_IMAGEMAGICK_CONVERT=/usr/bin/convert

# -DIMAGEMAGICK_CODERS
TS_IMAGEMAGICK_CONVERT_CODERS=/usr/lib/x86_64-linux-gnu/ImageMagick-6.9.12/modules-Q16/coders

# -DIMAGEMAGICK_CONFIG
TS_IMAGEMAGICK_CONVERT_CONFIG=/usr/lib/x86_64-linux-gnu/ImageMagick-6.9.12/config-Q16

# alfresco-transform-core-aio-boot-2.7.0-A1.jar
TS_JAR=/opt/alfresco/bin/alfresco-transform-core-aio-boot-2.7.0-A1.jar


#
# Function Start Transform Service
#
TsStart()
{
nohup java -XX:MinRAMPercentage=50 -XX:MaxRAMPercentage=80 \
-DPDFRENDERER_EXE="$TS_PDFRENDERER" \
-DLIBREOFFICE_HOME="$TS_OFFICE" \
-DIMAGEMAGICK_ROOT="$TS_IMAGEMAGICK" \
-DIMAGEMAGICK_DYN="$TS_IMAGEMAGICK" \
-DIMAGEMAGICK_EXE="$TS_IMAGEMAGICK_CONVERT" \
-DIMAGEMAGICK_CODERS="$TS_IMAGEMAGICK_CONVERT_CODERS" \
-DIMAGEMAGICK_CONFIG="$TS_IMAGEMAGICK_CONVERT_CONFIG" \
-DACTIVEMQ_URL="failover:(tcp://localhost:61616)?timeout=3000" \
-jar $TS_JAR \
/tmp 2>> /dev/null >>/dev/null \
& echo $! > $PID_PATH_NAME
}

#
# Function Stop Transform Service
#
TsStop()
{
# PID=$(cat $PID_PATH_NAME);
# printf "\n $SERVICE_NAME stoping ... \n"
/bin/kill $PID;
# printf "\n $SERVICE_NAME stopped ...\n"
# rm $PID_PATH_NAME
}


echo "Process id path: $PID_PATH_NAME"

case $1 in
start)
echo "Starting $SERVICE_NAME ..."
if [ ! -f $PID_PATH_NAME ]; then
TsStart
printf "\n $SERVICE_NAME started ...\n"
else
printf "\n $SERVICE_NAME is already running ...\n"
fi
;;

stop)
if [ -f $PID_PATH_NAME ]; then
PID=$(cat $PID_PATH_NAME);
printf "\n $SERVICE_NAME stoping ... \n"
TsStop
printf "\n $SERVICE_NAME stopped ...\n"
rm $PID_PATH_NAME
else
printf "\n $SERVICE_NAME is not running ...\n"
fi
;;

restart)
if [ -f $PID_PATH_NAME ]; then
#
# Process Stop
PID=$(cat $PID_PATH_NAME);
printf "\n Stoping $SERVICE_NAME ... \n"
TsStop
printf "\n Stopped $SERVICE_NAME ...\n"
rm $PID_PATH_NAME
#
# Process Start
echo "Starting $SERVICE_NAME ..."
TsStart
printf "\n Started $SERVICE_NAME ...\n"
else
printf "\n $SERVICE_NAME is not running ...\n"
fi
esac

• settiamo i permessi del file

sudo chmod +x /opt/alfresco/bin/alfrescots.sh

• create a systemd unit

sudo nano /usr/lib/systemd/system/alfrescots.service

[Unit]
Description=Alfresco Transform Service
After=network.target

[Service]
Type=forking
Restart=always

User=alfresco
Group=alfresco

ExecStart=/opt/alfresco/bin/alfrescots.sh start
ExecStop=/opt/alfresco/bin/alfrescots.sh stop

[Install]
WantedBy=multi-user.target

• ricarichiamo le unit di systemd

sudo systemctl daemon-reload

8. Primo avvio

• Creiamo alfresco-global.properties

sudo nano /opt/alfresco/tomcat/shared/classes/alfresco-global.properties

# The server mode. Set value here
# UNKNOWN | TEST | BACKUP | PRODUCTION
system.serverMode=TEST

dir.license.external=/opt/alfresco/licenses

dir.root=/opt/alfresco/data
dir.keystore=/opt/alfresco/data/keystore

# Solr setup
#index.subsystem.name=solr6
#solr.secureComms=https
#solr.port=8983

# MariaDB setting
db.name=alfresco
db.username=alfresco
db.password=alfrescoPass
db.port=3306
db.host=127.0.0.1
db.pool.max=275
db.driver=org.mariadb.jdbc.Driver
db.url=jdbc:mariadb://127.0.0.1:3306/alfresco?useUnicode=yes&characterEncoding=UTF-8

user.name.caseSensitive=true
domain.name.caseSensitive=false
domain.separator=


#ActiveMQ setup
messaging.broker.url=failover:(tcp://localhost:61616)?timeout=3000

#Context generator
alfresco.context=alfresco
alfresco.host=www.example.com
alfresco.port=8080
alfresco.protocol=http
share.context=share
share.host=www.example.com
share.port=8080
share.protocol=http

imap.server.enabled=false
alfresco.rmi.services.host=0.0.0.0
smart.folders.enabled=false
#smart.folders.enabled=true
#smart.folders.model=alfresco/model/smartfolder.xml
#smart.folders.model.labels=alfresco/messages/smartfolder-model"

#This property is default true, here it it for information purpose.
local.transform.service.enabled=true
localTransform.core-aio.url=http://localhost:8090/
transform.service.enabled=true
transform.service.cronExpression=4 30 0/1 * * ?
transform.service.initialAndOnError.cronExpression=0/10 * * * * ?

• settiamo il corretto proprietario

sudo chown alfresco:alfresco -R /opt/alfresco

• primo avvio (NB: processo manuale)

sudo systemctl start mariadb
sudo systemctl start activemq
sudo systemctl start alfrescots
sudo systemctl start alfresco

• con un web broweser accediamo a http://< alfresco IP >:8080/, autentichiamoci con l’account default (Username: admin Password: admin) e verifichiamo e proviamo tutto
  NB: il sistema di ricerca non è in esecuzione.

• stoppiamo lo stack alfresco

sudo systemctl stop alfresco
sudo systemctl stop alfrescots
sudo systemctl stop mariadb
sudo systemctl stop activemq

9. Installiamo Alfresco Search Services

( https://docs.alfresco.com/search-services/latest/ )

• Aggiornare la configurazione di Alfresco

sudo nano /opt/alfresco/tomcat/shared/classes/alfresco-global.properties

[ ... ]
#
# Solr setup TLS
#index.subsystem.name=solr6
#solr.secureComms=https
#solr.port=8983

#
# Solr setup SECRET
index.subsystem.name=solr6
solr.secureComms=secret
solr.port=8983
solr.sharedSecret=MySecretPassword
[ ... ]

• Scarichiamo il pacchetto alfresco-search-services-2.0.9.1.zip, dezippiamolo e pubblichiamolo

cd ~ && cd SW
wget https://nexus.alfresco.com/nexus/service/local/repositories/releases/content/org/alfresco/alfresco-search-services/2.0.9.1/alfresco-search-services-2.0.9.1.zip

unzip alfresco-search-services-2.0.9.1.zip
sudo mv alfresco-search-services /opt/alfresco/alfresco-search

• personalizzare /opt/alfresco/alfresco-search/solrhome/conf/shared.properties

sudo nano /opt/alfresco/alfresco-search/solrhome/conf/shared.properties

[ ... ]
alfresco.identifier.property.0={http://www.alfresco.org/model/content/1.0}creator
alfresco.identifier.property.1={http://www.alfresco.org/model/content/1.0}modifier
alfresco.identifier.property.2={http://www.alfresco.org/model/content/1.0}userName
alfresco.identifier.property.3={http://www.alfresco.org/model/content/1.0}authorityName
alfresco.identifier.property.4={http://www.alfresco.org/model/content/1.0}lockOwner

# Suggestable Propeties
alfresco.suggestable.property.0={http://www.alfresco.org/model/content/1.0}name
alfresco.suggestable.property.1={http://www.alfresco.org/model/content/1.0}title
alfresco.suggestable.property.2={http://www.alfresco.org/model/content/1.0}description
alfresco.suggestable.property.3={http://www.alfresco.org/model/content/1.0}content

# Data types that support cross locale/word splitting/token patterns if tokenised
alfresco.cross.locale.property.0={http://www.alfresco.org/model/content/1.0}name
alfresco.cross.locale.property.1={http://www.alfresco.org/model/content/1.0}lockOwner

# Data types that support cross locale/word splitting/token patterns if tokenised
alfresco.cross.locale.datatype.0={http://www.alfresco.org/model/dictionary/1.0}text
alfresco.cross.locale.datatype.1={http://www.alfresco.org/model/dictionary/1.0}content
alfresco.cross.locale.datatype.2={http://www.alfresco.org/model/dictionary/1.0}mltext
[ ... ]

• settare Solr
  NB: in produzione la memoria XMS e XMX va aumentata almeno a 4GB altrimenti crascia durante l’indicizzazione!

sudo nano /opt/alfresco/alfresco-search/solr.in.sh

[ ... ]
#SOLR_JAVA_MEM="-Xms2g -Xmx2g"
[ ... ]
#SOLR_LOGS_DIR=../../logs
#LOG4J_PROPS=$SOLR_LOGS_DIR/log4j.properties
[ ... ]
SOLR_SOLR_HOST=localhost
SOLR_ALFRESCO_HOST=localhost
[ ... ]
#SOLR_OPTS="$SOLR_OPTS -Dsolr.jetty.request.header.size=1000000 -Dsolr.jetty.threads.stop.timeout=300000 -Ddisable.configEdit=true"
[ ... ]

• correggere i permessi

sudo chown alfresco:alfresco -R /opt/alfresco/alfresco-search
sudo chmod +x /opt/alfresco/alfresco-search/solr.in.sh
sudo rm /opt/alfresco/alfresco-search/solr.in.cmd

• creare la unit di avvio per SystemD

sudo nano /usr/lib/systemd/system/alfresco-search.service

[Unit]
Description=Alfresco search service Solr
After=network.target

[Service]
Type=forking
Restart=always

User=alfresco
Group=alfresco

LimitNOFILE=8192:65536

ExecStart=/opt/alfresco/alfresco-search/solr/bin/solr start -a '-Dcreate.alfresco.defaults=alfresco,archive
-Dalfresco.secureComms=secret -Dalfresco.secureComms.secret=MySecretPassword'
ExecStop=/opt/alfresco/alfresco-search/solr/bin/solr stop -all

[Install]
WantedBy=multi-user.target

• carichiamo la unit e testiamo alfresco-search

sudo systemctl daemon-reload
sudo systemctl start alfresco-search
systemctl status alfresco-search
sudo systemctl stop alfresco-search

10. Avvio completo di test

• Procediamo con un avvio completo manuale

sudo systemctl stop activemq
sudo systemctl stop mariadb
sudo systemctl stop alfrescots
sudo systemctl stop alfresco-search
sudo systemctl stop alfresco

sudo systemctl start activemq
sudo systemctl start mariadb
sudo systemctl start alfrescots
sudo systemctl start alfresco-search
sudo systemctl start alfresco

systemctl status activemq
systemctl status mariadb
systemctl status alfrescots
systemctl status alfresco-search
systemctl status alfresco

• con un web broweser accediamo a http://< alfresco IP >:8080/, autentichiamoci con l’account default (Username: admin Password: admin) e verifichiamo e proviamo tutto.

• completato il test stoppiamo lo stack alfresco

sudo systemctl stop activemq
sudo systemctl stop mariadb
sudo systemctl stop alfrescots
sudo systemctl stop alfresco-search
sudo systemctl stop alfresco

11. Installiamo il Reverse Proxy

Adding a Reverse proxy
Question about upload Issue in Alfresco 6.2 Content Services ?
Error uploading large files (>2gb) through nginx reverse proxy to container

• Installiamo Nginx

sudo apt install nginx

• creare il file di configurazione example.com.conf

sudo nano /etc/nginx/sites-available/example.com.conf

# worker_processes 1;
#
#events {
# worker_connections 1024;
#}
#
#http {
server {
listen 80;
listen [::]:80;

server_name example.com www.example.com;

root /var/www/example.com/html;
index index.html;

client_max_body_size 0;

set $allowOriginSite *;
proxy_pass_request_headers on;
proxy_pass_header Set-Cookie;

# External settings, do not remove
#ENV_ACCESS_LOG

proxy_next_upstream error timeout invalid_header http_500 http_502 http_503 http_504;
proxy_redirect off;
proxy_buffering off;
proxy_set_header Host $host:$server_port;
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_pass_header Set-Cookie;

# Protect access to SOLR APIs
location ~ ^(/.*/service/api/solr/.*)$ {return 403;}
location ~ ^(/.*/s/api/solr/.*)$ {return 403;}
location ~ ^(/.*/wcservice/api/solr/.*)$ {return 403;}
location ~ ^(/.*/wcs/api/solr/.*)$ {return 403;}

location ~ ^(/.*/proxy/.*/api/solr/.*)$ {return 403 ;}
location ~ ^(/.*/-default-/proxy/.*/api/.*)$ {return 403;}

# Prometheus settings, do not remove
#PROMETHEUS_LOCATION

#location / {
# proxy_pass http://localhost:8080;
#}
location /alfresco/ {
# proxy_pass http://alfresco:8080;
#
# If using external proxy / load balancer (for initial redirect if no trailing slash)
# absolute_redirect off;

proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Forwarded-Proto $scheme;
proxy_set_header Host $http_host;
proxy_http_version 1.1;
proxy_pass http://localhost:8080/alfresco/;
}

location /share/ {
proxy_pass_header Set-Cookie;
proxy_set_header Origin "";
proxy_set_header Proxy "";
proxy_set_header X-Forwarded-Server $host;
proxy_set_header X-Forwarded-Host $http_host;
proxy_set_header Referer "";

proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Forwarded-Proto $scheme;
proxy_set_header Host $http_host;
proxy_http_version 1.1;

# Allow large file upload
client_max_body_size 0;

proxy_pass http://localhost:8080/share/;
}

# Share settings, do not remove
#SHARE_LOCATION

# Control Center settings, do not remove
#CONTROL_CENTER_LOCATION

# ADW settings, do not remove
#ADW_LOCATION

# ACA settings, do not remove
#ACA_LOCATION

# Sync service settings, do not remove
#SYNCSERVICE_LOCATION
}
#}

• creiamo la directory della web root

sudo mkdir -p /var/www/example.com/html

• creiamo una pagina index.html personalizzata

sudo nano /var/www/example.com/html/index.html

<!DOCTYPE html>
<html>
<head>
<title>My Custom ECM home Page</title>
</head>
<body><h1>My ECM</h1>
<p>
<a href="/portal/./alfresco">Alfresco Home</a><br>
<a href="/portal/./share">Alfresco Share</a><br>
<a href="/portal/./page1.html">Page 1</a><br>
<a href="/portal/./page2.html">Page 2</a><br>
<a href="/portal/./page3.html">Page 3</a>
</p>
</body>
</html>

• impostiamo il corretto proprietario

sudo chown www-data:www-data -R /var/www/example.com/html

• abilitiamo example.com

sudo ln -s /etc/nginx/sites-available/example.com.conf /etc/nginx/sites-enabled/

• avvio di test di Nginx

sudo systemctl disable nginx
sudo systemctl restart nginx
systemctl status nginx
sudo systemctl stop nginx

12. Attivazione del firewall

• Abilitare ufw

sudo ufw allow 'Nginx Full'
sudo ufw allow 'OpenSSH'
sudo ufw enable
Command may disrupt existing ssh connections. Proceed with operation (y|n)? y
Firewall is active and enabled on system startup

sudo ufw status

13. Automazione dell’avvio

• Stoppare e impostare i servizi

sudo systemctl stop nginx
sudo systemctl stop alfresco
sudo systemctl stop alfresco-search
sudo systemctl stop alfrescots
sudo systemctl stop activemq
sudo systemctl stop mariadb

sudo systemctl disable nginx
sudo systemctl disable alfresco
sudo systemctl disable alfresco-search
sudo systemctl disable alfrescots
sudo systemctl disable activemq
sudo systemctl disable mariadb

• Creare il file /etc/init.d/alfrescoctl

sudo nano /etc/init.d/alfrescoctl

#!/bin/bash

### BEGIN INIT INFO
# Provides: alfrescoctl
# Required-Start: $remote_fs $syslog
# Required-Stop: $remote_fs $syslog
# Default-Start: 2 3 4 5
# Default-Stop: 2
# Short-Description: Alfresco Stack Controller
### END INIT INFO

set -e

ACTION=$1

case "$ACTION" in
start)
systemctl start mariadb
systemctl start activemq
systemctl start alfrescots
systemctl start alfresco-search
sleep 30
systemctl start alfresco
systemctl start nginx
;;

stop)
systemctl stop nginx
systemctl stop alfresco
systemctl stop alfresco-search
systemctl stop alfrescots
systemctl stop activemq
systemctl stop mariadb
;;

restart)
systemctl stop nginx
systemctl stop alfresco
systemctl stop alfresco-search
systemctl stop alfrescots
systemctl stop activemq
systemctl stop mariadb

sleep 60

systemctl start mariadb
systemctl start activemq
systemctl start alfrescots
systemctl start alfresco-search
sleep 30
systemctl start alfresco
systemctl start nginx
;;
status)
systemctl status mariadb
systemctl status activemq
systemctl status alfrescots
systemctl status alfresco-search
systemctl status alfresco
systemctl status nginx
;;

*)
echo "Usage: alfrescoctl {start|stop|restart|status}"
exit 1
;;
esac

exit 0

• settare i permessi

sudo chmod +x /etc/init.d/alfrescoctl

• ricarichiamo le unit di SystemD

sudo systemctl daemon-reload

14. Completamento

• Check dello stack

sudo systemctl start alfrescoctl
systemctl status alfrescoctl

• accedere all’URL http://www.example.com e verificare
• abilitare alfrescoctl e riavviare il server

sudo systemctl enable alfrescoctl
sudo systemctl reboot

• dopo il riavvio verificare il corretto funzionamento.

15. Tuning

Riportiamo alcuni accorgimenti importanti per la nostra installazione di Alfresco se la portiamo in produzione.
Ricordiamoci che la versione cummunity non supporta tutte le funzioni della enterprise e non sono disponibili tutti i moduli.
Attenzione anche ai manuali ufficili che non descrivono sempre in modo completo le configurazioni per la Community.

15.1 Alfresco componenti aggiuntivi

Componenti aggiuntivi (ufficiali):

• Alfresco Digital Workspace 4.4
• Alfresco Mobile Workspace
• Alfresco Media Management 1.4
• Alfresco Intelligence Services 3.1
• Alfresco Sync Service 5.0
• Alfresco Desktop Sync 1.18
• Alfresco Enterprise Viewer 4.0
• Alfresco Office Services 3.0
• Alfresco Content Accelerator 4.0

15.2 Aggregare i log

Per aggregare tutti i log in /opt/alfresco/logs:

• stoppare lo stack

sudo systemctl stop alfrescoctl

• applicare gli AMP se non fatto ancora

sudo su - -s /bin/bash alfresco
cd /opt/alfresco/bin
bash apply_amps.sh
exit

• creare le directory

sudo mkdir alfresco
sudo mkdir ROOT
sudo mkdir share
sudo mkdir _vti_bin

• estrarre i WAR

sudo unzip ROOT.war -d ./ROOT
sudo unzip alfresco.war -d ./alfresco
sudo unzip share.war -d ./share
sudo unzip _vti_bin.war -d ./_vti_bin
sudo rm alfresco.war ROOT.war share.war _vti_bin.war

• aggiornare i log4j2.properties come segue

sudo nano /opt/alfresco/tomcat/webapps/alfresco/WEB-INF/classes/log4j2.properties

[ ... ]
#appender.rolling.fileName=alfresco.log
#appender.rolling.filePattern=alfresco.log.%d{yyyy-MM-dd}
appender.rolling.fileName=/opt/alfresco/logs/alfresco.log
appender.rolling.filePattern=/opt/alfresco/logs/alfresco.log.%d{yyyy-MM-dd}
[ ... ]

sudo nano /opt/alfresco/tomcat/webapps/share/WEB-INF/classes/log4j2.properties

[ ... ]
#appender.rolling.fileName=share.log
#appender.rolling.filePattern=share.log.%d{yyyy-MM-dd}
appender.rolling.fileName=/opt/alfresco/logs/share.log
appender.rolling.filePattern=/opt/alfresco/logs/share.log.%d{yyyy-MM-dd}
[ ... ]

sudo nano /opt/alfresco/alfresco-search/logs/log4j.properties

[ ... ]
#log4j.appender.file.File=${solr.log}/solr.log
log4j.appender.file.File=/opt/alfresco/logs/solr.log
[ ... ]

• cencellare il bitcode di Tomcat in work

sudo rm -R /opt/alfresco/tomcat/work/Catalina/localhost

• cencellare i WAR ed il backup

sudo rm -R /opt/alfresco/tomcat/webapps/*.war
sudo rm -R /opt/alfresco/tomcat/webapps/*.bak

• impostare il corretto proprietario

sudo chown alfresco:alfresco /opt/alfresco/tomcat
sudo chown alfresco:alfresco /opt/alfresco/alfresco-search

15.3 Tuning dei limiti

In produzione vanno gestiti i limiti nei nodi *nix. Esempio:

sudo nano /etc/security/limits.conf

[ ... ]
alfresco soft nofile 64536
alfresco hard nofile 65536

15.4 Integrazione Email

In produzione è opportuno imposta Alfreso come installazione produzione e attivare il pooling automatico alla casella email e l’invio.
Queste impostazioni si attivano in alfresco-global.properties.

Esempio:

sudo nano /opt/alfresco/tomcat/shared/classes/alfresco-global.properties

[ ... ]

system.serverMode=PRODUCTION

[ ... ]

mail.host=smtp.example.com
mail.port=25
mail.username=Questo indirizzo email è protetto dagli spambots. È necessario abilitare JavaScript per vederlo.
mail.password=mypassword
mail.encoding=UTF-8
mail.from.default=Questo indirizzo email è protetto dagli spambots. È necessario abilitare JavaScript per vederlo.
mail.smtp.auth=true

[ ... ]

email.inbound.enabled=true

# Email Server properties
#-------------
email.server.enabled=true
email.server.port=25
email.server.domain=example.com
email.inbound.unknownUser=anonymous

# A comma separated list of email REGEX patterns of allowed senders.
# If there are any values in the list then all sender email addresses
# must match. For example:
# .*\@alfresco\.com, .*\@alfresco\.org
# Allow anyone:
#-------------
#email.server.allowed.senders=.*

[ ... ]

imap.server.enabled=true
imap.server.port=143
imap.server.host=example.com

sudo systemctl restart alfrescoctl

15.5 Sicurezza

È importante gestire i servizi di sicurezza nei server *nix: possono bloccare il corretto funzionamento di Alfresco e non è opportuno disattivarli, anche se è una scelta valida per staging didattici.
I sistemi di sicurezza abituali da gestire sono:

• SeLinux: per RedHat e derivate;
• AppArmor: per Debia e derivate.

15.6 Certificati Let’s Encrypt

Per un server in produzione è quasi obbligatorio attivare il protocollo HTTPS per l’accesso attraverso il reverse proxy Nginx.
A questo scopo possiamo usare CertBot: Certbot Instructions

16. WebGrafia

Transform Services install on community 23.x
Welcome to Alfresco SSL Generator
Alfresco Content Services - Blog
Alfresco Community Edition 23.2 Release Notes
ACS Nginx Proxy
alfresco-reverse-proxy
CertBot
Configure Transform Service

Alfresco Content Services 23.x
Alfresco Search Services 2.0
Alfresco Content Accelerator 4.0
Alfresco Digital Workspace 4.4
Alfresco Mobile Workspace
Alfresco Media Management 1.4
Alfresco Intelligence Services 3.1
Alfresco Sync Service 5.0
Alfresco Desktop Sync 1.18
Alfresco Enterprise Viewer 4.0
Alfresco Office Services 3.0
